DURBAL WLK20-00-500 杆端关节轴承--DURBAL WLK20-00-500参数报价

目录 DURBAL WLK20-00-500 杆端关节轴承

DURBAL WLK 20 - 00 - 500 图纸

型号	WLK20-00-500
类型	杆端关节轴承
Type (version with circular lubrication groove and lubrication hole for relubrication)	WLK 20 - 01 - 500
d (mm)	20
D (mm)	50
B (mm)	25
C (mm)	18
d1 (mm)	24.3
倾斜角度α (°)	7
Gewicht (kg)	0.25
rotational speed limit n max. (min-1)	825
axial factor Y	2.46
axial factor Y0	2.58
基本额定载荷C (kN)	7.9
基本额定载荷Co (kN)	3.5
radial clearance CN (m)	10 - 30
d (mm)	20

Type	Type (version with circular lubrication groove and lubrication hole for relubrication)	d (mm)	D (mm)	B (mm)	C (mm)	d1 (mm)	tilt angle alpha (°)	Gewicht (kg)	rotational speed limit n max. (min-1)	axial factor Y	axial factor Y0	basic load rating dyn C (kN)	basic load rating stat Co (kN)	radial clearance CN (m)	d (mm)
WLK 20 - 00 - 500	WLK 20 - 01 - 500	20	50	25	18	24.3	7	0.25	825	2.46	2.58	7.9	3.5	10 - 30	20

产品代号: WLK20-00-500
类型：杆端关节轴承
上架日期：2021-06-08
应用行业:模具,工业链条,木工机械,包装机,制冷空调机械,轿车,锻压机械,固体废物处理设备,电工仪器仪表,环保机械,机床
近似产品:WLK14-00-500 WLK 08 - 60 - 500 WLK 12 - 60 - 500 WLK 10 - 00 - 500 WLK 40 - 00 - 500 WLK 30 - 60 - 500 WLK 20 - 60 - 500 WLK08-00-500 WLK 14 - 00 - 500 WLK 16 - 60 - 500
WLK08-60-500 WLK25-60-500 WLK35-00-500 WLK40-00-500 WLK08-00-500 WLK18-60-500 WLK16-60-500 WLK12-60-500 WLK14-00-500 WLK20-00-500 WLK18-00-500 WLK22-00-500
BEF10-91-502 BEF12-21-502L DGE12E DGE35LO DGK25SK EFN10-20-501 EM60-21-502L DGAR / DGAL 80 UK-2RS DGEC 360 FBAS DGEZ 120 ES (-2RS) DGE 40 ES (-2RS) DSA / DSAL 45 ES (-2RS) GLK 08-20-500 GCURL 120 LRE7
