目录 DURBAL EFN70-21 杆端关节轴承

• DURBAL EFN70-21 图纸
• DURBAL EFN70-21 基本参数
• DURBAL EFN70-21 咨询订购
• DURBAL EFN70-21 供货商

DURBAL EFN 70 - 21 基本参数

type	right hand thread	left hand thread	d (mm)	G	B (mm)	C1 (mm)	h1 (mm)	d1 (mm)	d2 (mm)	d3 (mm)	dk (mm)	l3 (mm)	l4 (mm)	l5 (mm)	l7 (mm)	W (mm)	tilt angle alpha (°)	weight (kg)	basic load rating dyn C (kN)	basic load rating stat Co (kN)	radial clearance CN (m)	d (mm)
EFN 70 - 21	-501	-502	70	M 56 x 4	49	40	200	77	162	80.5	92	56	281	35	88	70	6	8	315	850	72 - 142	70

• 产品代号: EFN70-21
• 类型：杆端关节轴承
• 上架日期：2021-06-15
• 应用行业:装卸机械,压实机械,水污染防治设备,制药机械,电工机械,电料装备,气体压缩机,摩托车,成分分析仪,载货汽车,工程机械
• 近似产品:EFN-12-20-501 EFN12-20-502L BEFN 16 - 20 EFN60-20-501 BEFN 05 - 81 EFN-06-20-502L EFN30-20-502L EFN 10 - 21 EFN35-20-501 EFN 45 - 30
  BEFN14-20 EFN40-30 EFN50-21 EFN35-20 EFN40-21 EFN45-31 EFN15-30 EFN60-20 BEFN18-20 BEFN30-80 EFN70-20 EFN15-30
• BEM05-60-502 BEM25-60-501 BEF16-20-501 BEF22-90-501 BRF10-60-501 BRTM16-00-502L DG12PB EM-15-20-502L FG 25 52 EEM FG 65 120 BEFN 14 - 80 DGE 45 UK-2RS DGF 32 LO DGF 63 LO 16-61-936

咨询订购DURBAL EFN 70 - 21 请填写下面信息

DURBAL EFN 70 - 21 供货商

八零动力专业销售EFN 70 - 21，库存EFN70-21大量现货，与DURBAL合作，批量订购EFN 70 - 21，咨询热线：022-58519723

DURBAL EFN 70 - 21 杆端关节轴承我选八零动力，德国DURBAL EFN70-21品种全，价格优，质量有保证！杆端关节轴承大客户热线：022-58519723
