DURBAL DPHS/DPHSL25 杆端关节轴承--DURBAL DPHS/DPHSL25Rod ends maintenance required参数报价

目录 DURBAL DPHS/DPHSL25 杆端关节轴承

DURBAL DPHS / DPHSL 25 图纸

type	d (mm)	d1 (mm)	d2 (mm)	d3 (mm)	d4 (mm)	dk (mm)	G	B (mm)	C1 (mm)	l3 (mm)	l4 (mm)	l7 (mm)	W (mm)	h1 (mm)	tilt angle alpha (°)	weight (kg)	basic load rating dyn C (kN)	basic load rating stat Co (kN)	radial clearance CN (m)	d (mm)
DPHS / DPHSL 25	25	29.5	60	33.5	42	42.86	M 24 x 2	31	22	42	124	30	36	94	15	0.73	24.6	54.4	8 - 55	25

产品代号: DPHS/DPHSL25
类型：杆端关节轴承 Rod ends maintenance required
上架日期：2021-06-13
应用行业:蓄电池,水泥设备,电工仪器仪表,电线电缆,包装机,成分分析仪,摩托车,电料装备,输送机,印刷机械,石油钻采机械
近似产品:DPHSL16 DPHS / DPHSL 16 M16x1,5 DPHS / DPHSL 30 M27x2 DPHSL06 DPHSL08 DPHSL20 DPHSL14 DPHSL05 DPHS / DPHSL 14 DPHSL18
DPHS/DPHSL14M14x1,5 DPHS/DPHSL14 DPHS/DPHSL20 DPHS/DPHSL12 DPHS/DPHSL18 DPHS/DPHSL30M27x2 DPHS/DPHSL22 DPHS/DPHSL6 DPHS/DPHSL10M10x1,25 DPHS/DPHSL25 DPHS/DPHSL22 DPHS/DPHSL30
BEM05-90-501 BEF14-60-501 BEF25-90-502 BRTF35-00-502 BRTM20-30-501 DGE20ES DSIZPL-07-S EFN10-21-502L EFN50-21-502L EMN-35-20-502L FGL 8 24 DG 25 x 50 DGE 20 LO DGF 70 LO GCRL 62 EE
