目录 DURBAL BRTF3/4-00 杆端关节轴承
DURBAL BRTF 3/4 - 00 图纸
| 型号 | BRTF3/4-00 |
|---|---|
| 类型 | 杆端关节轴承 |
| 右旋螺纹 | -501 |
| 左旋螺纹 | -502 |
| d (inches) | .750 |
| G | 3/4 - 16 UNF |
| B (inches) | .984 |
| C1 (inches) | .708 |
| h1 (inches) | 3.051 |
| d1 (inches) | .956 |
| d2 (inches) | 1.968 |
| d3 (inches) | 1.082 |
| d4 (inches) | 1.338 |
| l3 (inches) | 1.299 |
| l4 (inches) | 3.926 |
| l5 (inches) | .409 |
| l7 (inches) | 1.043 |
| W (inches) | 1.181 |
| 倾斜角度α (°) | 7 |
| 重量 (kg) | 0.386 |
DURBAL BRTF 3/4 - 00 基本参数
- 产品代号: BRTF3/4-00
- 类型：杆端关节轴承
- 上架日期：2021-06-08
- 应用行业:锻压机械,工矿车辆,汽车,炼油机械,标准紧固件,农业机械,冶金机械,金属切削机床,照相机,粉末冶金制品,矿山机械
- 近似产品:BRTF 12 - 90 BRTF10-01-501 BRTF40-00-502 BRTF 1/1 - 01 BRTF12-00-502L BRTF16-00-502L BRTF 10 - 61* BRTF 35 - 00 BRTF12-01-502 BRTF16-00-502
BRTF25-60* BRTF30-90* BRTF10-60 BRTF10-61* BRTF35-30 BRTF12-30 BRTF10-31 BRTF20-90 BRTF12-01 BRTF16-60 BRTF1/2-00 BRTF5/8-00 - BEMN22-90-501 DGAR80UK-2RS DPHS18 EF20-20-502L EMN-17-20-502L GCRL 22 EE GC 13 BEFN 20 - 80 DG 18 x 36 M18x1,5 DGE 20 UK-2RS DGEZ 38 ES (-2RS) DSG 10 PB LR31 AR 24 120 210 Linear table with screw-type drive and ball rail system AXLT325
| type | right hand thread | left hand thread | d (inches) | G | B (inches) | C1 (inches) | h1 (inches) | d1 (inches) | d2 (inches) | d3 (inches) | d4 (inches) | l3 (inches) | l4 (inches) | l5 (inches) | l7 (inches) | W (inches) | tilt angle alpha (°) | weight (kg) | rotational speed limit n max. (min-1) | basic load rating dyn C (kN) | basic load rating stat Co (kN) | radial clearance CN (m) | d (inches) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| BRTF 3/4 - 00 | -501 | -502 | .750 | 3/4 - 16 UNF | .984 | .708 | 3.051 | .956 | 1.968 | 1.082 | 1.338 | 1.299 | 3.926 | .409 | 1.043 | 1.181 | 7 | 0.386 | 825 | 16.7 | 11.5 | 10 - 30 | .750 |
咨询订购DURBAL BRTF 3/4 - 00 请填写下面信息
DURBALBRTF 3/4 - 00 近期销售记录
河南省洛阳市涧西区龙鳞路一街…… 辛先生咨询的杜巴丽BRTF3/4-00已经送达
桥西区长丰路4号5栋1单元6…… 柴先生咨询的杜巴丽BRTF3/4-00已经送达
DURBAL BRTF 3/4 - 00 供货商
八零动力专业销售BRTF 3/4 - 00，库存BRTF3/4-00大量现货，与DURBAL合作，批量订购BRTF 3/4 - 00，咨询热线：022-58519723
DURBAL BRTF 3/4 - 00 杆端关节轴承我选八零动力，德国DURBAL BRTF3/4-00品种全，价格优，质量有保证！杆端关节轴承大客户热线：022-58519723
